Classic Allparts

Plate No.

Part No.

Product

Stock
Available

Secondhand
Available

Price

[ 3 ] 70-3903 SLUDGE TUBE - CRANKSHAFT 3.000 $33.00Each

[ 4 ] 71-2800 SCREWED PLUG FOR SLUDGE TRAP T140 35.000 $14.50Each

[ 4 ] 71-2800A SCREWED PLUG T140 (ALLEN KEY) 12.000 $13.25Each

[ 4 ] 70-3905 PLUG CRANKSHAFT ALLEN DRIVE 650 CC PRE UNIT 2.000 $10.35Each

[ 5 ] 71-2425 FLYWHEEL 0 Y $984.10Each

[ 5c ] 70-1511 BUSH - T120 SMALL END BUSH 10.000 $20.00Each

[ 6 ] 71-2799 FLYWHEEL BOLT 6.000 $8.75Each

[ 6 ] 72-0004 FLYWHEEL BOLT TRI CRANK 4.000 $8.75Each

[ 6 ] 70-6328 FLYWHEEL BOLT TRI 6.000 $17.25Each

[ 6 ] 71-3552 FLYWHEEL BOLT 12.000 $8.75Each

[ 7 ] 71-1003 WASHER FOR CRANKSHAFT FLYWHEEL BOLT 15.000 $0.90Each

[ 8 ] 70-3907 BOLT - 26 CEI FLYWHEEL TO CRANK BOLTS 3.000 $9.65Each

[ 8a ] 70-1562 BOLT - CRANK BOLT - 3 PIECE CRANK 6.000 $18.15Each

[ 8 ] 21-2183 CRANKSHAFT STUD L 3/8 IN. O.A. T140 12.000 $4.40Each

[ 8 ] 70-3114 STUD - CRANKSHAFT END 5.000 $5.90Each

[ 9 ] 71-3006 CONNECTING ROD T140 1.000 $263.30Each

[ 9 ] 70-9525 CONROD - T120 CONROD ASSEMBLY 0 $280.50Each

[ 10 ] 70-6576 CONNECTING ROD BOLT UNF 4.000 $25.00Each

[ 10 ] 70-9914 CONNECTING ROD BOLT T140,T100, 20.000 $17.45Each

[ 11 ] 60-3761 NUT - LESTER STAR NUT FOR BIG END BOLT 26.000 $2.20Each

[ 11 ] 21-7091 BIG END NUT T140 12.000 $1.75Each

[ 11 ] 70-2922 CONNECTING ROD NUT 26 TPI 8.000 $5.00Each

[ 11 ] 21-2016 CONNECTING ROD NUT UNF - 60-3761 6.000 $11.00Each

[ 12 ] 70-3586 BIG END SHELL SET STD SEE 99-7040 0 $46.00Each

[ 12 ] 99-7041G BIG END SHELL SET .010 (GLACIER) 2.000 $67.00Each

[ 12 ] 99-7040G BIG END SHELL SET STANDARD (GLACIER) 0 $67.00Each

[ 12 ] 99-7042G BIG END SHELL SET +020 TRI 650/750 GLACIER 6.000 $67.00Each

[ 12 ] 70-3586AE/020 BIG END SHELL SET AE .020 1.000 $86.25Each

[ 12 ] 99-7042 BIG END SHELL SET +020 TRI 650/750 3.000 $44.00Each

[ 12 ] 70-3586AE/010 BIG END SHELL SET AE .010 4.000 $86.25Each

[ 12 ] 99-9961 BIG END SHELL SET 040 9.000 $40.00Each

[ 12 ] 99-7041 BIG END SHELL SET 0.010 ENGLISH 0 $40.00Each

[ 12 ] 70-3586AE/040 BIG END SHELL SET AE .040 0 $67.00Each

[ 12 ] 99-7040 BIG END SHELL SET STANDARD 3.000 $70.00Each

[ 12 ] 70-3586AE/030 BIG END SHELL SET AE .030 0 $67.00Each

[ 12 ] 99-9960 BIG END SHELL SET .030 15.000 $40.00Each

[ 13b ] 70-2891/020 PISTON ASSY TRI 71MM +020 (650 IRON HEAD PRE UNIT) 4.000 $237.40Each

[ 13aa ] 70-3615/020 PISTON ASSY TRI 63MM +020 P/UNIT T100 9:1 1.000 $366.20Pair

[ 13c ] 70-3610/040 PISTON ASSY TRI 650 (+040 ALLOY HEAD PRE UNIT) 4.000 $237.40Each

[ 13 ] 70-3525 PISTON ASSY TRI 63MM STD P/UNIT 5T GPM 0 $366.65Each

[ 13d ] 70-9488/020 PISTON ASSY TRI 71MM +020 650 UNIT T120 PR 4.000 $215.00Each

[ 13c ] 70-3610/060 PISTON ASSY TRI 650 (+060 ALLOY HEAD PRE UNIT) 4.000 $237.40Each

[ 13aa ] 70-3615/040 PISTON ASSY TRI 63MM +040 P/UNIT T100 9:1 1.000 $295.55Pair

[ 13 ] 70-3525/040 PISTON ASSY TRI 63MM +040 P/UNIT 5TGPM 0 $366.65Pair

[ 13aa ] 70-3615/060 PISTON ASSY TRI 63MM +060 P/UNIT T100 9:1 0 $366.20Each

[ 13 ] 70-3525/060 PISTON ASSY TRI 63MM +060 P/UNIT 5TGPM 0 $366.65Pair

[ 13j ] 19255/020 PISTON ASSY TRI +020 T140 750 (STD COMP) HEPOLITE 0 $448.55Each

[ 13h ] 17844/080 PISTON ASSY TRI (+080 UNIT) S/COMP 650 UNIT HEPOLITE 1.000 $448.55Pair

[ 13 ] 70-2927 PISTON ASSY TRI (P/UNIT 5T 63MM STD, CP29) PAIR 1.000 $260.35Each

[ 13d ] 79-9488/080 PISTON ASSY TRI (+080 UNIT) S/COMP 650 UNIT 0 $253.00Each

[ 13d ] 79-9488/040 PISTON ASSY TRI (+040 UNIT) S/COMP 650 UNIT 5.000 $253.00Each

[ 13d ] 79-9488/060 PISTON ASSY TRI (+060 UNIT) S/COMP 650 UNIT 3.000 $253.00Each

[ 13j ] 19255/060 PISTON ASSY TRI +060 T140 750 (STD COMP) HEPOLITE 0 $448.55Each

[ 13aa ] 70-3615/STD PISTON ASSY TRI 63MM STD P/UNIT T100 9:1 0 $366.20Each

[ 13j ] 19255/040 PISTON ASSY TRI +040 T140 750 (STD COMP) HEPOLITE. 4.000 $448.55Each

[ 13 ] 70-2927/040 PISTON ASSY TRI (P/UNIT 5T 63MM+ 040, CP29) PAIR 0 $260.35Pair

[ 13d ] 79-9488 PISTON ASSY TRI (STD UNIT) S/COMP 650 UNIT 4.000 $204.25Each

[ 13b ] 70-2891/040 PISTON ASSY TRI 71MM +040 (650 IRON HEAD PRE UNIT) 5.000 $237.40Each

[ 13h ] 17844 PISTON ASSY TRI HEP(STD UNIT) S/COMP 650 UNIT PAIR 6.000 $448.55Pair

[ 13j ] 19255 PISTON ASSY TRI STD T140 750 (STD COMP) HEPOLITE 10.000 $448.55Pair

[ 13h ] 17844/060 PISTON ASSY TRI HEP(+060 UNIT) S/COMP 650 UNIT PAIR 3.000 $448.55Pair

[ 13h ] 17844/020 PISTON ASSY TRI HEP(+020 UNIT) S/COMP 650 UNIT PAIR 2.000 $410.00Pair

[ 13h ] 17844/040 PISTON ASSY TRI HEP(+040 UNIT) S/COMP 650 UNIT PAIR 10.000 $448.55Pair

[ 13e ] 71-3676 PISTON ASSY TRI T140 76MM STD (STD COMP) PAIR 2.000 $235.55Pair

[ 13d ] 70-9488/STD PISTON ASSY TRIUMPH STD 71MM T120 PAIR 9:1 2.000 $275.00Pair

[ 13e ] 71-3676/020 PISTON ASSY TRIUMPH T140 76MM +020 (STD COMP) PAIR 2.000 $254.00Pair

[ 13 ] 70-2927/020 PISTON ASSY TRI UMPH(P/UNIT 5T 63MM+ 020, CP29) PAIR 2.000 $287.50Each

[ 13e ] 71-3676/040 PISTON ASSY TRI T140 76MM +040 (STD COMP) PAIR SEE HEP NUMBER 0 $235.55Pair

[ 13e ] 71-3676/060 PISTON ASSY TRI T140 76MM +060 (STD COMP) PAIR 1.000 $235.55Pair

[ 13d ] 70-9488/080 PISTON ASSY TRI 71MM +080 650 UNIT T120 PR 2.000 $253.00Each

[ 13c ] 70-3610/020 PISTON ASSY TRI 71MM 650 (+.020 ALLOY HEAD PRE UNIT) L/COMP 3.000 $237.40Each

[ 13b ] 70-2891/060 PISTON ASSY TRI 71MM +060 (650 IRON HEAD PRE UNIT) 3.000 $250.00Each

[ 13d ] 70-9488/040 PISTON ASSY TRI 71MM +040 650 UNIT T120 PR 13.000 $235.55Each

[ 13d ] 70-9488/060 PISTON ASSY TRI 71MM +060 650 UNIT T120 PR 3.000 $253.00Each

[ 13c ] 70-3610 PISTON ASSY TRI 71MM 650 (STD ALLOY HEAD PRE UNIT)(SUIT 650 UNIT L/COMP) 4.000 $237.40Each

[ 13f ] 71-7086/060 PISTON ASSY TRI 750 (+060 T140) FOR UNLEADED FUEL 0 $273.70Pair

[ 13f ] 71-7086 PISTON ASSY TRI 750 (STD T140) FOR UNLEADED FUEL 5.000 $274.20Pair

[ 13f ] 71-7086/040 PISTON ASSY TRI 750 (+.040 T140) FOR UNLEADED FUEL 2.000 $274.20Pair

[ 13b ] 70-2891 PISTON ASSY TRI 71MM STD (650 IRON HEAD PRE UNIT) 4.000 $237.40Each

[ 13f ] 71-7086/020 PISTON ASSY TRI 750 (+.020 T140) FOR UNLEADED FUEL 7.000 $274.20Pair

[ 13 ] 70-3525/020 PISTON ASSY TRI 63MM +020 P/UNIT 0 $366.65Pair

[ 13d ] 79-9488/020 PISTON ASSY TRI (+020 UNIT) S/COMP 650 UNIT 1.000 $253.00Each

[ 14b ] R11050/060 PISTON RING SET 71MM +060 (TRI 650) HEP 0 $110.40Each

[ 14b ] R11050/040 PISTON RING SET 71MM +040 (TRI 650) HEP 21.000 $110.40Each

[ 14b ] 99-9905 PISTON RING SET 71MM +060 (TRI 650) 2.000 $74.75Each

[ 14b ] R11050/080 PISTON RING SET 71MM +080 (TRI 650) HEP 0 $110.40Each

[ 14c ] R26490/020 PISTON RING SET 76MM +020 (TRIUMPH 750) SEE 99-3791 3.000 $99.00Each

[ 14c ] 99-3792 PISTON RING SET 76MM +040 (T140 750) 3.000 $90.00Each

[ 14b ] 99-3784 PISTON RING SET 71MM STD (TRI 650) 3.000 $84.00Each

[ 14c ] 99-3791 PISTON RING SET 76MM +020 ( T140 750) SEE R26490 0 $60.95Each

[ 14e ] 99-3778/040 PISTON RING SET +040 TRI 250 (1967-71) 0 $42.05Each

[ 14e ] 99-3778/020 PISTON RING SET +020 TRI 250 (1967-71) 0 $42.05Each

[ 14 ] 99-3706 PISTON RING SET 63MM .040 P/UNIT 500 2.000 $64.25Each

[ 14 ] 99-3704 PISTON RING SET 63MM .020 P/UNIT 500cc 1.000 $89.70Each

[ 14b ] R11050/020 PISTON RING SET 71MM +020 (TRI 650) HEP 35.000 $110.40Each

[ 14b ] 99-3787 PISTON RING SET 71MM +040 (TRI 650) 3.000 $74.75Each

[ 14 ] 99-3702 PISTON RING SET 63MM STD P/UNIT 1.000 $60.95Each

[ 14b ] 99-3786 PISTON RING SET 71MM +020 (TRI 650) 9.000 $74.75Each

[ 14c ] 99-9904 PISTON RING SET 76MM +060 (T140 750) 2.000 $75.00Each

[ 14c ] 99-3789 PISTON RING SET 76MM STD (T140 750) 2.000 $67.85Each

[ 14 ] 99-3789/060 PISTON RING SET 76MM +060 TRIUMPH T140 750cc 1.000 $84.00Each

[ 14 ] 99-3789/040 PISTON RING SET 76MM TRIUMPH (+040 T140 750) 3.000 $90.00Each

[ 14a ] 99-3752/STD PISTON RING SET STD ( 69MM TRIUMPH 500CC ) 1.000 $134.00Each

[ 14e ] 99-3778 PISTON RING SET STD TRI 250 (1967-71) 5.000 $42.05Each

[ 14c ] R26490/STD PISTON RING SET 76MM STD (TRI 750) HEP 5.000 $110.40Each

[ 16 ] 70-6861 PIN - GUDGEON PIN 3.000 $31.25Each

[ 16 ] 71-3354 GUDGEON PIN SHORT (650) 13.000 $31.25Each

[ 17 ] 71-3700 CIRCLIP T140 PISTON 66-0954 37.000 $2.50Each

[ 17 ] 70-6869 CIRCLIP - 650 PISTON B RANGE GPM 23.000 $2.50Each

[ 17 ] 70-6869A GUDGEON PIN CIRCLIP GPM TRI T100,T120 29.000 $2.00Each

[ 18 ] 70-1591 BEARING CRANKSHAFT D/S & T/S C3 3.000 $70.00Each

[ 18 ] 60-4167 MAIN BEARING- RIGHT TIMING SIDE C3 0 $49.00Each

[ 18 ] 60-7362 MAIN BEARING RIGHT TIMING SIDE 10.000 $117.00Each

[ 19 ] 71-2662 SPROCKET ENGINE DUPLEX LATE 4.000 $82.55Each

[ 19a ] 71-2660 SHIM 030 T140 CRANKSHAFT SHIM/DIST PIECE 0 $2.05Each

[ 19a ] 70-8038 SHIM +.010 CRANK SHAFT 650/750 14.000 $2.30Each

[ 19 ] 70-3108/22 ENGINE SPROCKET PRE UNIT(22 TEETH) old stock 0 $68.55Each

[ 19 ] 70-3108/24 ENGINE SPROCKET PRE UNIT (24TEETH) 1.000 $82.00Each

[ 19 ] 70-3108/23 ENGINE SPROCKET PRE UNIT(23 TEETH) 1.000 $72.45Each

[ 19 ] 70-5446 ENGINE SPROCKET, 29T DUPLEX UP 1966 SEAL 1.000 $104.00Each

[ 19 ] 70-5450 ENGINE SPROCKET 29T DUPLEX 1966 ON NO SEAL 1.000 $88.00Each

[ 19 ] 71-3542 ENGINE SPROCKET 29 TEETH TRIPLEX T140 1.000 $105.80Each

[ 19 ] 70-3108/21 ENGINE SPROCKET PRE UNIT (21 TEETH) 1.000 $79.00Each

[ 19 ] 70-3108 ENGINE SPROCKET ALT MODEL P/UNIT 29 TEETH 0 $68.55Each

[ 20 ] 70-4573 ALTERNATOR SPACER 650 1.000 $9.10Each

[ 20 ] 71-3544 ALTERNATOR SPACER T140 3.000 $9.10Each

[ 21 ] 71-0082 ROTOR KEY 39.000 $4.80Each

[ 22 ] 99-0739NG ROTOR NON GENUINE 0 $225.40Each

[ 22 ] 99-0739 ROTOR LUCAS GEN SEE LU54202298 0 $247.85Each

[ 23 ] 21-7024 ALTERNATOR STAR LOCK WASHER 24.000 $1.75Each

[ 23 ] 70-3975 TAB WASHER - ROTOR LOCK NUT 9.000 $3.00Each

[ 24 ] 70-3977 ALTERNATOR NUT 650 0 $7.55Each

[ 24 ] 21-2182 ALTERNATOR NUT T140 15.000 $7.20Each

[ 25 ] 70-1580 KEY FOR TIMING PINION 13.000 $4.55Each

[ 26 ] 71-7679 TIMING PINION ELECT START 4.000 $73.40Each

[ 26 ] 70-4564 TIMING PINION 7.000 $73.40Each

[ 27 ] 71-2877 NUT TIMING PINION CRANKSHAFT 1973 ON 3.000 $9.50Each

[ 28 ] 71-7618 INTERMEDIATE CAM WHEEL (ELEC START T140) 0 $381.35Each

[ 28 ] 70-6159 GEAR - CAMSHAFT INTERMEDIATE GEAR 2.000 $74.10Each

[ 29 ] 70-0400 INTERMEDIATE WHEEL BUSH 4.000 $6.90Each

[ 30 ] 71-3666 CAMSHAFT PINION 6.000 $79.25Each

[ 31 ] 70-1558 KEY - ENGINE KEY CAMSHAFT 30.000 $4.55Each

[ 32 ] 71-1007 INLET CAMSHAFT NUT 8.000 $12.85Each

[ 33 ] 70-6523 EXHAUST CAMSHAFT NUT 16.000 $6.90Each

[ 34a ] 70-3275 INLET & EXHAUST CAMSHAFT TRIUMPH 1952-62 4.000 $189.00Each

[ 34 ] 71-7016 INLET CAMSHAFT 3.000 $173.90Each

[ 34 ] 70-3134 CAMSHAFT INLET - TRIUMPHT120 0 $182.20Each

[ 34a ] 70-6147 THRUXTON CAM T120 0 $333.50Each

[ 35 ] 71-7017 EXHAUST CAMSHAFT 9.000 $173.90Each

[ 35 ] 70-9989 CAMSHAFT - UNIT 650 HALF RACE EXHAUST 0 $182.20Each

[ 37 ] 70-3300 CLAMPING WASHER UNIT & P/UNIT 2.000 $3.80Each

[ 38 ] 70-2879C2. BEARING MAIN LH D/S ROLLER C2 NOT RHP 2.000 $99.00Each

[ 39 ] 70-3902 PLUG, CRANKSHAFT OILWAY 10.000 $1.30Each

[ 46 ] 70-3876 OIL SEAL TRI CRANK 8.000 $7.40Each

[ 46 ] 97-1168 FORK OIL SEAL TRIUMPH AND CRANKCASE/T20 HIGH GEAR SUITS ALL 4.000 $8.05Each

[ 47 ] 70-2256 SPRING BREATHER T120 8.000 $7.00Each

[ 48 ] 70-2254 BREATHER DISC CAM TANGS 68-0131 4.000 $34.00Each

n/a 71-2663 SPACER T140 ENGINE SPROCKET 1.000 $9.00Each

n/a 71-6861 650 GUD PIN 8.000 $14.70Each

n/a 70-4700 THIMBLE TACHO DRIVE 2.000 $5.80Each

n/a MRJ1 BEARING TIMING SIDE EARLY TRIUMPH 1.000 $135.00Each

n/a 70-8785 CRANK LOCK TAB 19.000 $4.00Each

n/a 71-7017R CAMSHAFT EXHAUST T120/T140 SPITFIRE 2.000 $327.00Each

n/a 70-2879 BEARING MAIN LH D/S ROLLER RHP C2 6.000 $162.00Each

n/a 70-1591C3 BEARING CRANKSHAFT D/S & T/S RHP C3 4.000 $78.00Each

n/a 70-4565 NUT CRANKSHAFT TIMING SIDE UP TO 1972 8.000 $7.00Each

n/a 23182/3 PISTON ASSY TRI +040 T140 750 (STD COMP) HEPOLITE 4.000 $448.25Each

n/a 70-9488/040H PISTON ASSY TRI 71MM +040 HARRIS 10.000 $402.50Each

n/a R26490/040 PISTON RING SET 76MM +040 (TRI 750) HEP 8.000 $120.00Each

n/a 97-3704/STD PISTON RING SET STD TRI (P/UNIT 500) 1.000 $86.25Each

n/a 71-7647/65 PISTON RING SET TRIUMPH TSS ETC 4MM 1.5MM 0 $145.00Each

n/a R11050/STD PISTON RING SET 71MM STD (TRI 650) HEP 2.000 $95.00Each

n/a 19916 PISTON ASSY TRIDENT - SEE TRIDENT PAGE 0 $542.25Each

n/a 70-1592 BEARING TRIUMPH TIMING SIDE EARLY 2.000 $95.00Each

n/a 99-3708 PISTON RING SET 63MM .060 P/UNIT 500CC 2.000 $117.00Each
